The straight-arm aerial work platform can be lifted directly in a straight line, making it easy to use. With its large reach, it can access work areas higher than other aerial work platforms. The maximum working height is 24m, the platform load capacity is 460kg, providing the industry's largest working height and stronger load-bearing capacity at the same level. The application of the work platform's rapid lifting function eliminates the need to operate folding arms, allowing the platform to be lowered to the ground with greatly improved work efficiency. Equipped with a remote information processing pre-interface, an active defense protection system, an anti-harsh environment protection component, thumb rocker steering, and mechanical anti-crushing devices.
|
type |
HSJBZ23M-LI aerial work platform specifications |
|
|
host demand skill art join count |
size size |
|
|
Overall length (storage dimensions): 9470mm |
Total length (transportation dimensions): 7150mm |
|
|
Machine width: 2450mm |
Height: 2770mm |
|
|
Platform size: 2440x900x1150mm |
Wheelbase: 2520mm |
|
|
Maximum working height: 24000mm |
Maximum platform height: 22150mm |
|
|
Maximum working range: 16,500 mm |
Swivel support: 19 inches |
|
|
Performance |
||
|
Maximum load capacity: 300 (unlimited) / 460 (limited) kg |
Speed (storage): 5.2km/h |
|
|
Speed (rise or extend): 0.6km/h |
Arm amplitude range: -5 to +75 |
|
|
Revolving angle of the turntable: 360 degrees continuously |
Tail length: 1700mm |
|
|
Platform rotation angle: ±90° |
Minimum turning radius (outside/inside): 5450/2690mm |
|
|
Total machine weight: 10500kg |
Maximum climbing capacity (weight end up): 45% (24°) |
|
|
Maximum climbing capacity (downward from the counterweight end): 30% (17°) |
Maximum side slope: 25% (14°) |
|
|
Power source |
||
|
Battery: 420Ah/51.2v/21.5 KWH / 207kg |
Oil pump motor (AC): 32V/10kW/314 displacement |
|
|
Auxiliary power unit (emergency pump): 12V DC |
Drive motor: 3.3Kw/32V AC |
|
|
Drive: 4x4x2 |
Fuel tank: 75L |
|
|
Charger: 220V/16A/3500W |
||
|
Other sizes |
||
|
Blue box size: 2.44x0.9x1.15m |
Maximum (minimum) length of the upper arm: 6.9/16m |
|
|
Tire: 315/55D20, diameter: 0.79m |
Weight: 1.7t |
|
